This fully automatic juice production line processes 500 kg of raw fruit per hour. It handles apples, oranges, peaches, and pears with ease. This complete apple juice plant can transform fresh fruits into high-quality juice, jam, or dried fruit products. It helps beverage factories, fruit processing companies, and agricultural enterprises achieve efficient production with consistent results. We have successfully exported this industrial apple juice processing equipment to the United States, Russia, Mexico, Germany, Poland, Brazil, Thailand, and many other countries worldwide.
Request Solution for My Business
Specifications of Apple Orange Juice Production Line
| Specification | Details |
| Model | 500KG Bottled Apple Orange Juice Production Line |
| Designed Capacity | 500 kg of raw fruit per hour (Customizable for smaller or larger capacity) |
| Applicable Fruits | Apples, oranges, peaches, pears |
| End Products | Pure juice, mixed juice, jam, dried fruit |
| Power Requirement | 380V, 50Hz, ≥ 80KW (Customizable for different country standards) |
| Compressed Air | 0.1m³/h required |
| Recommended Operators | 5 people (2 for sorting/cleaning, 1 for production, 2 for filling) |
| Key Process | Washing, Crushing, Juicing, Pasteurization, Filling, Capping |
| Materials | SUS304 stainless steel (food grade) |
| Certifications | CE, FDA, ISO 22000, HALAL |
Request Brochure or Catalog
How Does A Fruit Juice Processing Line Work?
- Workers place fresh fruits into the cleaning machine. The machine removes dirt and impurities completely.
- A hoist lifts the clean fruits into the juicer. The equipment crushes and presses the fruits to extract pure juice. For oranges, we use a special double roller peeling and juicing machine.
- After juicing, the juice flows into a collection tank. A centrifugal pump moves it to the storage tank. The operator can mix ingredients in the sterilization ingredient tank at this stage.
- Then, the pasteurization tank heats the juice to eliminate bacteria. This step ensures food safety and extends shelf life.
- Finally, the filling machine pours juice into bottles. Workers cap the bottles and apply labels with the semi-automatic labeling machine. The finished products are now ready for packaging and shipment.
Get Videos & Shipment Details
Industrial Apple Juice Processing Equipment
The complete apple juice plant includes the following machines:
- Bubble Washing Machine: Thoroughly washes fruits with water to remove surface dirt and residue.
- Conveyor Elevator: Lifts clean fruits to the juicer automatically for continuous processing.
- Screw Press Juicer Machine: Crushes and presses apples and pears to extract fresh juice efficiently.
- Double Roller Peeling and Juicing Machine: Processes oranges by peeling and juicing in one step.
- Fruit Pulp Collection Tank: Stores freshly extracted juice temporarily before further processing.
- Centrifugal Pumps: Transfers juice between tanks through sanitary stainless steel pipes.
- Juice Storage Tank: Holds juice with gentle agitation to maintain consistency.
- Ingredient Sterilization Tank: Heats juice and mixes ingredients for flavor adjustment.
- Pasteurization Tank: Heats bottled juice to precise temperatures for safe preservation.
- Automatic Filling Machine: Fills bottles with accurate volumes ranging from 100 to 500ml.
- Bottle Sealing Machine: Seals bottles tightly at speeds of 800 to 1200 bottles per hour.
- Automatic Labeling Machine: Applies labels with ±0.5mm accuracy and prints date codes.
- Pipes, Valves, and Fittings: Connect all equipment with food-grade stainless steel components.
- Control System: Manages all operations with automated controls and temperature monitoring.
- Air Compressor: Provides compressed air for pneumatic equipment in the filling section.
Request Brochure or Catalog
Why Our Fruit Juice Production Line Stands Out
- Versatile Raw Material Handling: This flexible fruit juice production line can also process oranges, peaches, and pears, allowing you to diversify your product range easily.
- Food-Grade Hygienic Material: This fruit juice production line features all components constructed from SUS304 stainless steel, ensuring long-lasting durability and complete food safety compliance for global markets.
- Precise Temperature Control: The control system includes automatic temperature regulation with ±1°C accuracy, allowing operators to maintain consistent juice quality throughout every production batch.
- Streamlined Bottling Process: The integrated apple juice filling and packaging line includes precise filling, secure capping, and accurate labeling in one compact workflow, minimizing manual handling.
- Flexible Filling Options: The apple juice filling and packaging line section operates at adjustable speeds, giving producers flexibility to match different bottle sizes and daily production requirements.
Get Factory Quote | WhatsApp/Tel: +8613838509601
What are the Benefits of the Automatic Juice Production Line?
- Intelligent Control: This automatic juice production line is equipped with a precision control system to ensure the stable quality of the fruit juice production line.
- Global Adaptation: This fruit juice processing line supports voltage customization to adapt to different power standards of the industrial apple juice processing equipment market.
- Matching Packaging: The apple juice filling and packaging line perfectly fits the whole line with high efficiency and accurate filling for bottled products.
- Safety Compliant: The apple juice processing line has strict sterilization links to meet international food standards for the juice production line export.
- Fast Delivery: This automatic juice production line has a short production cycle and quick delivery to help clients put the fruit juice production line into use fast.
- Space-Saving: The complete apple juice plant has a compact structure and rational layout to save workshop space for small and medium enterprises.
Get Factory Quote | WhatsApp/Tel: +8613838509601
FAQs of Fruit Jam Juice Production Line
Yes, our apple juice production line produces pure fresh juice, concentrated juice, blended juice drinks, and apple jam. We adjust the process based on your target market preferences.
This fruit juice processing line carries CE, FDA, ISO 22000, and HALAL certifications. The equipment meets international food safety standards for Europe, America, and the Middle Eastern markets.
You need five people total. Two workers handle fruit sorting and cleaning, one person monitors the production system, and two workers manage the filling and packaging section.
Yes, we customize the electrical system for your country. We offer 220V/60Hz for North America, 400V/50Hz for Europe, and 230V/50Hz for Southeast Asia with brand-name electrical components.
Delivery takes 30 to 45 days for standard configurations. We coordinate shipping and provide full support for customs clearance in your country.
Yes, our technicians travel to your factory for installation and training. We ensure the line runs properly before we leave, and we provide ongoing technical support.
Get Factory Quote | WhatsApp/Tel: +8613838509601
Why Choose Foodmax Machines?
Foodmax Machines stands as a trusted fruit production line manufacturer with 20 years of industry experience. We have supplied complete apple juice plants to more than 20 countries across Southeast Asia, Europe, Africa, and South America. Our international certifications include CE, FDA, ISO 22000, and HALAL, so your equipment meets global standards automatically. We provide complete support from custom design to overseas installation and operator training. Our after-sales network includes service partners in key regions, 24-hour multilingual technical support, and fast spare parts delivery worldwide.
